Single lens-Wall washer light

AS Series Lens -Single lens 35mm 3.8°, 4°, 6°, 15°

Name: AJS35D22H3.8G/4G/6G/15G
Diameter: 35mm
Height: 23.33mm
Beam Angle: 3.8°, 4°, 6°, 15°

AVE Series Lens -Single lens 14mm 17°, 15x50°

Name: AVE14D9H17G/1550G
Diameter: 14.0mm
Height: 8.70mm
Beam Angle: 17°, 15x50°

AST Series Lens -Single lens 20mm Asy 30° for area lighting

Name: AST20DP30G
Diameter: 20.0mm
Height: 7.67mm
Beam Angle: Asy 30°

AST Series Lens -Single lens 20mm 120° for area and street lighting

Name: AST20D120G
Diameter: 20.0mm
Height: 4.85mm
Beam Angle: 120°

AFL series -Single lens 16mm 20x90° oval beam with fix pins and installation tape

Name: AFL16D9H2090G
Diameter: 16.11mm
Height: 8.72mm
Beam Angle: 20x90°

AE series -Single lens 10mm with side emitter beam 180°

Name: AE10D6H180G
Diameter: 10.0mm
Height: 11.63mm
Beam Angle: 180°

AT series -Single lens 16mm with narrow height 9.7mm

Name: AT series
Diameter: 16.1mm
Height: 9.7mm
Beam Angle: 13°30°

AYseries -Single lens 22mm with square holder + Tape assembly

Name: AY series Square holder
Diameter: 21.57mm
Height: 13
Beam Angle: 6°15°30°45°

AX series -Single lens 22mm with narrow height 9.6mm +Tape assembly

Name: AX series
Diameter: 22.4mm
Height: 9.63
Beam Angle: 10°25°40°60°30X65°

AF series -Single lens 22mm with 3M Tape option

Name: AF series
Diameter: 21.3mm
Height: 12.34mm
Beam Angle: 10°, 15°, 25°, 30°, 40°, 60°, 80°, 10x45°, 10x60°, 30x60°

AN series -Single lens Narrow size φ 10.8 mm

Name: AN Series
Diameter: 10.8mm
Height: 7.0mm
Beam Angle: 15°, 30°, 40°, 15x60°

AW Series- Single lens waterproof one-piece lens 22mm

Name: AW Series
Diameter: 22.5mm
Height: 12.4mm
Beam Angle: 15°,24°,30°,40°,60°, 15°x30°, 15°x45°,15°x60°

9LEDs group lens 3535LED 15° for wall washer lighting

Name: ASL239D9LED15G
Diameter: 239mm
Height: 29.03mm
Beam Angle: 15°

single lens with 3M tape 30°

Name: ALS21D30G
Diameter: 21.58mm
Height: 11.4mm
Beam Angle: 30°

single lens narrow spot beam  8~10°, with 3M Tape for option

Name: ALS21D10G
Diameter: 21.58mm
Height: 11.4mm
Beam Angle: 10°

single linear lens for window linear lighting, wall washer lighting, traffic signal lighting lens, 10°x100° oval beam

Name: ALS26D3535LED10X100G
Diameter: 26.1mm
Height: 12.8mm
Beam Angle: 10°*100°

Narrow beam LED lens is designed for surgery, dental light and other technical lighting requirements with a tight 5° beam.

Name: AYS29DH17-5G
Diameter: 29.1mm
Height: 17.0mm
Beam Angle:

Narrow beam LED lens is designed for surgery, dental light, torch light, wall washer light and other technical lighting requirements with a tight 5° beam.

Name: AYS29DH17-5G-HOLDER
Diameter: 29.1mm
Height: 17.0mm
Beam Angle:

AYS35D18G

Name: AYS35D18G
Diameter: 35.0
Height: 16.35
Beam Angle: 18°

AYS35D25G

Name: AYS35D25G
Diameter: 35.0
Height: 16.35
Beam Angle: 25°

AYS35D40G

Name: AYS35D40G
Diameter: 35.0
Height: 16.35
Beam Angle: 40°

Single lens for wall washer light with CREE LED XML-Color mixing narrow long beam 15x60°

Name: ALS23D1560G
Diameter: 23.0mm
Height: 11.16mm
Beam Angle: 15°*60°
